PIN 排針

PIN2.0-010
2.00mm pitch double row needle

PIN2.0-010

SMT VERTICAL / PIN CONNECTOR 1.0mm/1.50/mm2.00mm FEATURE ‧ 2.00mm pitch ‧ High temperature resistance APPLICATIONS ‧ Used in general connection devices in electronics, electrical appliances, meters, etc.


產品說明

COMMON SPECIFICATIONS

CharacteristicsSpecification
工作溫度範圍/Operating temperature range-40℃ to +105℃
絕緣電阻/Insulation resistance

1000MΩ Min

耐壓/Withstand voltage

AC 500V/min

尺寸/Dimension1.0/1.50/2.00mm
額定電流/Rated current

2.0APM

接觸阻抗/Contact resistance

20mΩ Max

DIMENSIONS










Unit:mm

ModelDimensions

PIN2.0-010

PIN2.0-010



PIN2.0-010
