1.25-B-NP

1.25 雙面接直插 FEATURE ‧ 1.25mm ‧ Wave soldering ‧ High temperature and corrosion resistance APPLICATIONS Smart home/home appliances, shared equipment, medical equipment, digital electronics, mobile phones/computers, printers

檔案下載產品詢價

1.25-B-NP

產品說明

COMMON SPECIFICATIONS

Characteristics	Specification
額定電流/Rated current	0.5A/PIN
額定電壓/Rated voltage	50V
耐電壓/Withstand voltage	200V
接觸電阻/Contact resistance	≤40mΩ
絕緣電阻/Insulation resistance	800MΩ
工作溫度/Operating temperature	-55℃-+85℃
