防水翹板開關

PR-2030series
PR-2030series
PR-2030series
PR-2030series
Waterproof multi-position rocker power switch

PR-2030series

IP65防水帶燈翹板開關 FEATURE ‧ 21.90mm*23.08mm ‧ 2 gears ‧ Illuminated double row feet APPLICATIONS ‧ Low-voltage electrical appliances, household appliances, instruments, electronic toys, drinking fountains


產品說明

COMMON SPECIFICATIONS


CharacteristicsSpecification
電流/Current6A 250VAC
接触电阻/Contact Resistance50MAX
操作溫度/Operating temperature-25℃+85℃
絕緣電阻/Insulation resistance500VDC 100MAX min
耐電壓/Withstand voltage1500VAC 1min
電器壽命/Electrical life1000000cycles


DIMENSIONS

ModelDimensions

PR-2030seriesPR-2030series

PR-2030series
