TM-1224 series

操縱桿電位器 FEATURE ‧ 16.00mm*16.00mm ‧ Loop operation ‧ Wave soldering APPLICATIONS ‧ Digital cameras, automobiles, health care products, robots and industrial machinery, game consoles, drones.

檔案下載產品詢價

產品說明

COMMON SPECIFICATIONS

Characteristics	Specification
全阻值/Total resistance	5KA~100KA
额定功率/Rated power	0.0125W
工作电流/Working current	100MA DC250V
滑杆行程/Travel of the slide bar	60°±6°
操作力距/Operating torque	160±40gf
寿命/life	2000000 Times
